KAC-9106D
330,00 €
Ενισχυτής Μονοφωνικός Class D Ψηφιακός με ισχύ Εξόδου 1Χ500 Watt στα 4 Οhms.
Τεχνικά Χαρακτηριστικά
1 x 500W RMS
Συμβατότητα 4Ω
Ρυθμιζόμενο φίλτρο χαμηλών συχνοτήτων
Infrasonic filter
Λειτουργία Bass Boost
Dual mono drive function
Class‐D
Alu. Die‐cast heat sink
Είσοδος απο ηχεία
Ενεργοποίηση απο σήμα
335x56x192mm
Key Features
| D-class Amplifier Circuit |
| Signal sensing turn-on |
| 2000 Watts max Output Power |
| 2Ω Load Capability |
| Cooling Fan |
| Built-in Low-pass filter |
| Built-in Infrasonic filter |
| Bass Boost function |
Amplifier Features
| Class D Amplifier | Yes |
| Load Capability | 2Ω Stable |
| Maximum power output | 2000W |
| Rated power output (4Ω) | 500W x 1 (4Ω) |
| Rated power output | 1000W x 1 (2Ω) |
| CEA-2006 Compliant | Yes |
| Low-pass Filter | Yes |
| Bass Boost Circuit | Yes |
| Infrasonic filter | Yes |
| Phase inverter 0°(Normal) / 180°(Reverse) | Yes |
| Switched Mode Power supply | Yes, with Power MOS-FET |
| Power Indicator | Yes |
| Blue Illumination | Yes |
| Signal Sensing Turn-on | Yes |
| Protection function | Yes |
| Line in | RCA |
| Line out | RCA |
| Speaker level Input | Yes |
| Single Side Terminals | Yes |
| Die-Cast Aluminium Heat Sink | Yes |
Amplifier-Specifications
| Maximum power output (4Ω) | 2000W x 1 |
| Rated power output (4Ω, 14,4V) | 500W x 1 (20Hz ~ 200Hz, 1%THD) |
| Rated power output (2Ω, 14,4V) | 1000W x 1 (100Hz, 1%THD) |
| Rated power output (CEA-2006) | 500Watts RMS x 1 at 4 ohms and 1% THD |
| Low-pass Filter | 50~200Hz (24dB/oct)(B-Channel) |
| Bass Boost Circuit | 0~18dB (Variable) |
| Bass Boost Frequency | 40Hz |
| Infrasonic filter | 20/50Hz (-24dB/oct) |
| RCA Input Sensitivity | 0.2 ~ 5V |
| Input Impedance | 10kΩ |
| Signal to Noise Ratio | 100dB |
| Signal to noise ratio (CEA-2006) | 76dBa (Reference: 1 Watt into 4 Ohms) |
| Frequency response (+0dB, -3dB) | 5Hz ~ 200Hz |
| Operating voltage | 14.4V (11V ～ 16V allowable) |
| Maximum current consumption | 65A |
| Dimensions (WxHxD) | 335 x 56 x 192(mm), |
| Weight | 2.8kg |
| Unit weight in individual package | 3.22 kg. |
